Round Ceramic Vacuum Disc Filter 5Kw Combined Water Washing System

Product Description:

The structure of ridges on two sides of the disc are different. These ridges consists a block surface to block and store the suspending solids. Open design of ridge external can keep the filter disc tight during the back washing process and ensure the back washing efficient, even if in a low water pressure. Cycled edge ensure the filtrate precision, and form the water channel, which increase the filtration precision to 5μ.

The filter disc is the core component of disc filter. A special grooved or ridged filter discs formed a certain dimensional channel, it can block the particle size larger than this channel to achieve the purpose of filtration. The disc filter has an excellent performance and lower consumption than traditional mechanical devices.

Working Principle:

The filter disc absorbs the slurry through holes by the function of vacuum negative pressure and form piled material layer. The filtrate shall be discharged from inside of filter plate through pipes, distribution valve and discharging tank.

After transferring the cake out of hopper, clean the filter cake and the cleaning can be omitted if not required.

The cake absorbed on the filter disc shall be transferred to the drying area and continue dewatering under vacuum effect.

After the cake dewatered, it transfers to the unloading area, and unload the cake with ceramic drawknife.

After that, the filter disc shall be washed in backwashing area by filter liquid or tap water, which will enter the inside of filter disc from distribution valve.

Features:

Support and Services:

The Disc Filter product technical support and services include:

• Expert assistance with installation, operation, and maintenance of the Disc Filter product
• Analysis of customer-specific requirements and recommendations for optimal filter selection and operation
• On-site technical support and troubleshooting services
• Product repair and refurbishment services
• Provision of spare parts and consumables
• Training programs for operators and maintenance personnel

Packing and Shipping:

The Disc Filter product will be packaged with care to ensure its safe delivery. The packaging will consist of a sturdy cardboard box with ample cushioning material to prevent any damage during shipping.

Once the product is packaged, it will be shipped via a reputable courier service. The shipping cost will depend on the destination and the weight of the package. The estimated shipping time will be provided at the time of purchase.

FAQ:

Q: What is the brand name of the disc filter?

A: The brand name of the disc filter is UNIVEE.

Q: Where is the disc filter manufactured?

A: The disc filter is manufactured in China.

Q: What is the capacity of the UNIVEE U-DF disc filter?

A: 0.2-1.2t/h·m2.

Q: Can the disc filter be used for wastewater treatment?

A: Yes, the UNIVEE U-DF-21 disc filter can be used for wastewater treatment, as well as other applications.
